We are a one source solution for your PCBA needs! Assembling flex requires special planning of material utilization and array configuration options. Incorporating stiffeners and fixtures for stability becomes a factor as well. We have decades of tribal knowledge on how to effectively handle flex through all phases of assembly and offer some of the most cutting edge capabilities with superior delivery and quality.

  • SMT, Thru Hole, Wave Soldering, ROHS, BGA’s Rework
  • Quickturn Prototypes
  • Onshore and Offshore Production Options
  • Cost Reduction Solutions
  • Consignment, Parts Management, and Storage
  • Program Management for Scheduled Deliveries
  • ISO13485, ISO9001, IPC-610
  • Trained J-STD-001 Assembly Technicians
  • Lockheed Approved Supplier
  • ITAR

.

ASSEMBLY CAPABILITIES

SpecificationsOnshoreOffshore
Build TypeFPC and Rigid CircuitsFPC and Rigid Circuits
Certifications

ISO13485, ISO 9001, IPC 610
ISO 9001, IPC 610
Standard Lead Time
5-10 days
4 weeks
SMT
Yes
Yes
Wave Solder
Yes
Yes
Min Pitch0.4 mm 0.5 mm
Min component size
1005
 0201
Rework
Yes
Yes
Box Build
Yes
Yes
BGA Rework
Yes
Yes
AOI
Yes
Yes
Lead Free Assembly
Yes
Yes
Leaded Assembly
Yes
Yes
Flying Probe Test
Yes
Yes
Conformal Coating
Yes
Yes
3D Xray
Yes
Yes
